Description

High quality range of switchboard instruments with Class 1
accuracy and which complies with American ANSI-C39.1
(1981) specifications. Available in 41
/2″ case size, the rugged
design characteristics meet the needs of the most demanding
environmental applications. This extensive range of analog
and digital/analog meters utilizes high shock and provides
1% accuracy for all RMS AC and DC ranges. The range offers
various customized options and features.
Description

Model 007 is a one piece flame retardant polycarbonate moulding with a black
matte finished bezel area, and a specially contoured window to minimize reflection
from adjacent light sources.
Scales are 240° moving iron and 250° moving coil with parallax error-free
platform dials. Standard dials are white matte with black printed scales and
bar knife-edge pointers.

Features:

• Designed for North American Market, complying with ANSI C39.1 standard,
• Class 1 accuracy,
• High accuracy LED display for maximum trend indication visibility,
• Withstand high levels of shock, vibration, dirt and humidity,
• Interchangeable with standard 4.5” switchboard instruments,
• Protected to enclosure code IP54,
• One piece moulded plastic shatterproof front cover,
• Tough, crystal clear polycarbonate windows,
• Parallax error-free platform dials,
• Rugged pivot and jewel movement design,
• Calibration for mounting other than vertical,
• Scaling to customer’s requirements,
