Description

The Honeywell 3080 is a miniature VRS (Variable Reluctant Speed) sensor used for speed sensing applications where sensor mounting area is extremely limited.

The 3080 series meets Mil-Std 202F Method 204D vibration standards, is made with a 10-32 UNF-2A mounting thread and comes in a 0.5" thread length.

• Output Voltage: 8V P-P min.
• Thread Length: 0.5 inches (12 mm)
• Coil Resistance: 155 Ohms max.
• Min. Surface Speed: 30 IPS (.75 m/Sec) Typical
• Gear Pitch Range: 32 DP or Coarser
• Operating Temperature: -40-225°F (-40-107°C)
• Meets Mil-Std 202F Method 204D Vibration Standards
• Includes 24" (600 mm) Leads

AVAILABILITY:

Additional Info

• VRS Sensors
• Leads
