Description

The Megger MIT525 is a 5kV insulation tester with a resistance measurement up to 10 TOhms. The MIT525 replaces the old MIT520/2. The MIT525 is smaller and lighter yet offers advanced features from the previous model. One of these features is the ability to take measurements when connected to line power/mains with a dead battery. Intelligent battery charging ensures the optimum charge rate as a function of battery level, resulting in minimum charge times.

Five preset voltage ranges are provided in insulation test mode, plus a user settable lock voltage range. Any selectable test voltage may be locked and restored via the selector switch, thereby increasing efficiency of commissioning and repetitive tests. Pre-configured diagnostic tests include Polarization Index (PI), Dielectric Absorption Ratio (DAR), Dielectric Discharge (DD), Step Voltage (SV) and Ramp Test.

The rugged, unique dual case design provides the ultimate protection for a portable instrument and a clip-on lead pouch ensures that leads remain with the instrument at all times. Simplicity of operation is achieved with two rotary switches and the large backlit display enables multiple results to be
displayed simultaneously.

Features:

• Industry best guard terminal accuracy
• Compact and lightweight for easy transport and use
• PI, IR, DAR, DD, SV and Ramp Test
• Unique dual case design provides additional user protection
• Lithium-ion battery – extended capacity, rapid charge
• Advanced memory with time/date stamp
• CAT-IV 600V safety rating on all terminals

Additional Info

• 5,000V
