Description

The Monarch Instruments Track-It™ DC Voltage Logger is a two channel battery powered stand alone compact data logger that records up to 32,000 or 64,000 samples of data, depending on configuration. The 5396-0513 Track-It™ features a range of 5 DCV and is easily configured using the included Track-It™ Software. Simply plug the logger into an open USB port on your PC and the software automatically identifies the logger. Configure the unit to start and stop recording at a predetermined time and date or only when an alarm condition is sensed. The sample storage rate can be set from 1 sample every 2 seconds to 1 sample every 24 hours.

The on board data storage is non-volatile so data will not be lost in the event of a depleted battery. The Track-It™ DC Voltage Logger can also be used to record ambient temperature if one or neither input is being used. Information displayed on the LCD is also user programmable and can be sequenced by pressing the logger button. A multicolored LED indicator notifies the user of alarms, or general activity.

Features:

• 5 DCV range
• ± 0.5% accuracy
• Up to 32,000 or 64,000 samples per recording session (depending on configuration)
• Push button to start recording immediately or program to start recording at a later time and date
• Multiple alarm set points
• Compact size
• Integral USB interface/connector (no cable required)
• Powerful interactive Track-It™ Software package included
• 1 year lithium battery
• High accuracy and repeatability
• Accurate internal clock (1 minute/year)
• Includes Track-It™ Data Logger, battery, DC Voltage Module & Software download

Typical Uses:

• Industrial process monitoring
• Trouble shooting problematic signals
• Productivity monitoring
• Remote indication

Additional Info

• DCV
• 2
