Description

The Sifam Tinsley THETA 20A is an AC Voltage Transducer which converts a sinusoidal AC Voltage signal into a load independent DC Current or a load independent DC Voltage signal proportional to the measured value. The THETA 20A is a field programmable unit and can be configured by the user with a range of inputs from 57-500V and with 0-1 DCmA, 0-20 DCmA, 4-20 DCmA, or 0-10 DCV outputs.

The THETA 20A can be ordered with or without a display, with single or dual outputs and with or without RS485 communication.

Features:

• TRMS AC Voltage Transducer
• Choose an Input Range from 57-500V
• Choice of 0-1 DCmA, 0-20 DCmA, 4-20 DCmA or 0-10 DCV outputs
• Available in Single or Dual output type
• Onsite selectable output type (DC current / DC voltage)
• Accuracy class 0.2 (IEC/ EN 60 688)
• Seven Segment LCD Display (optional)
• RS-485(Modbus) Communication (optional)
